Electrical:

• Type: Magnetic mount whip antenna
• Frequency: 600~960/1710~2700/3300~3800/4400~5950MHz
  VSWR: ≤2.5
• Impedance: 50ohms
• Gain: 6dBi
• Radiation: Omni-directional
• Polarization: Vertical
• Max Power: 50W

Mechanical:

• Antenna Size: base 81mm, Whip height: 295mm
• Operating temp.: -30 to +70 degree
• Storage temp.: -35 to +75 degree

Mounting

• Magnetic Base OD81mm
• Metal Ground Plane to get better gain

Pigtail Cable and connector:

• RG58 (OEM length is welcome)
• Connector: SMA, MCX, MMCX, BNC, FME, SMB, CRC9, TS9 and TNC...etc
• Or cutting open end

Made in Taiwan

OEM and ODM orders are welcome

Compliant with RoHS Directive
