Electrical:

• Frequency Range: 2400MHz - 2500MHz
• V.S.W.R (MAX):  1.5 :1
• Antenna Type:  Collinear
• Radiation: Omni Directional
• Gain (MAX): 5 dBi
• Polarization: Vertical
• Max. Power:  0.5 Watts
• Vertical Beam-with:  36 Deg
• Horizontal Beam-with:  360 Deg
• Impedance: 50 Ohm
• Antenna Design:  Dipole Array
• Internal Material:  PCB+Spring
• Connector: N-Female or N-Male

Mechanical:

• Length (MAX):  198 mm
• Diameter (MAX):  13mm
• Antenna Weght (G.W): 57 g
• Application: Indoor / Outdoor
• Radome Material:  White Fiberglass
• Wind Survival:  Greater then 150MPH
• Storage Temperature:  -40 to +80
• Operating Temperature:  -40 to +60
• Operating Humidity:  10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing

Mounting:

• N Female & N Male connector

Made in Taiwan

OEM and ODM orders are welcome

Compliant with RoHS Directive
