Hockey Puck Screw Mount antenna for 3G/GSM, 4G LTE, 433/868MHz, LoRa, CDMA or WiFi

Availability: In stock

Model number: E254

Part no.

Size (mm)

Frequency

GSM-04A

54.7x23.3

3G/GSM – 824-960/1710-2170MHz

4G-04A

4G/LTE – 800-960/1710-2170/2500-2700MHz

DI-04A

433/868MHz

CDMA-04A

CDMA – 850/1900MHz Dual Band

WIFI-04A

WiFi – 2.4GHz

GPS-04A

GPS Active Antenna

Features

  • Low Profile Puck Antenna
  • Supports GSM/3G , 4G LTE , 433/868MHz or WiFi frequencies
  • Fully Waterproof when mounted - IP67 waterpfoof
  • For indoor or outdoor use - UV resistant
  • Groundplane Independent
  • SMA-male connector (optional)
Inquiry
Quantity

Electrical:

  • Type: Screw Mount【Puck】
  • Frequency: available in 6 models
    GSM-04A:  3G/GSM – 824-960/1710-2170MHz
    4G-04A:  4G/LTE – 800-960/1710-2170/2500-2700MHz
    DI-04A:  433/868MHz
    CDMA-04A:  CDMA – 850/1900MHz Dual Band
    WIFI-04A:  WiFi – 2.4GHz
    GPS-04A:  GPS Active Antenna
  • VSWR: ≤2.0
  • Impedance: 50ohms
  • Gain: 0-3dBi
  • Radiation: Omni
  • Electrical wave: 1/2
  • Polarization: Vertical
  • Max Power: 10W

Mechanical:

  • Antenna Size: 54.7 x 23.3mm
  • Operating temp.: -30 to +70 degree
  • Storage temp.: -35 to +75 degree

Mounting

  • Screw Mount

Pigtail Cable and connector:

  • RG174/u or RG174/u-ds low loss cable - 3meter (OEM length is welcome)
  • Connector: SMA, MCX, MMCX, BNC, FME, SMB, CRC9, TS9 and TNC...etc
  • Or cutting open end

Made in Taiwan

OEM and ODM orders are welcome

Compliant with RoHS Directive
