Electrical:

• Type: Monopole antenna
• Frequency:  617~960/1427~1559/1710~2690/3300~5925MHz
• VSWR and Gain:

615~698MHz : <4.0;  Gain 0dBi
698~960MHz: <4.0;  Gain 1.6dBi
1427~1559MHz: <4.5;  Gain 2.8dBi
1710~2170MHz: <3.5;  Gain 3.5dBi
2300~2690MHz: <5.5;  Gain 2.1dBi
3300~5000MHz: <3.0;  Gain 0.7dBi
5150~5925MHz: <4.5;  Gain 1.2dBi

• Impedance: 50ohms
• Radiation: omni
• Polarization: Linear
• Max Power: 10W

Mechanical:

• Antenna length: 64.3mm
• Antenna Cover: PC
• Operating temp.: -20 to +75 degree
• Storage temp.: -20 to +80 degree
• Color: Black, welcome customized color
• Waterproof: IP67

Mounting:

• Right Angle SMA male (standard)    R/A

Made in Taiwan

OEM and ODM orders are welcome

Compliant with RoHS Directive
